Specifications

IR detector and lens
• IR resolution 320×256
• Detector pitch 30μm
• Thermal sensitivity ≤25mK@25℃
• Temperature accuracy ±2℃ or ±2%
• Temperature range -40℃ to 350℃
• Gas detection sensitivity 0.001ml/s
• Lens Standard：24° ×18° /Optional:14.5° × 10.8°
• Focus Auto & Manual ing
• LCD 4”Touch LCD，800×600 Pixels
• Viewfinder 0.6”OLED，800×600 Pixels
• Visual camera 5MP CMOS，Auto focus，One bright LED lamp
• Color palettes 10
• Zoom 1–8×continuous, Digital zoom
• Image adjustment Continuous/Manual
• Gas enhancement High sensitivity mode
• Video out HDMI
• Digital interface USB2.0 and WLAN，Data transfer to PC
• Measurement analysis
• Spot meter 10
• Area 5 boxes with max./min./average
• Profile 1 live line (horizontal or vertical)
• Isotherm Yes
• Difference temperature Delta temperature between
• measurement functions or reference temperature
• Alarm Audio or Color
• Emissivity correction Variable from 0.01 to 1.0
• Measurement corrections Reflected temperature,
• distance,atmospherictransmission,
• humidity, external optics
• Storage of images
• IR image format Standard JPEG, with 14 bits
• measurement raw data
• IR video format MEPG4
• Visual image format Standard JPEG
• Visual video format MEPG4
• Voice annotation 60 seconds voice
• Periodic image storage Every 10 seconds up to
• 24 hours
• Storage media 16G Removable TF memory
• card, up to 64G
• Others
• Setup Day/Time/Language
• Laser pointer Class 2, Semiconductor
• diode laser, 1 mW, 635nm (red)
• Power
• Battery 7.2VRechargeable Li-ion battery，
• operating time≥3 hours
• Start-up time Typically 5 min. @ 25°C
• Environmental data
• Operating temperature range -20℃～+50℃
• Storage temperature range -30℃～+60℃
• Humidity(operating&storage) ≤95%
• Encapsulation IP 54 (IEC 60529)
• Physical data
• Camera weight ≤2.5kg
• Camera size (L×W ×H) 305×172×145mm
• Tripod mounting UNC ¼"-20

 Detectable Gases

• Sulfur Hexafluoride (SF6) ,
• Ammonia (NH3),
• Ethylene,
• Acetic Acid,
• Allyl Bromide,
• Acetyl Chloride,
• Allyl Bromide,
• Allyl Chloride,
• Allyl Fluoride,
• Bromomethane,
• Chlorine
• Dioxide,
• Ethyl Cyanoacrylate,
• Furan,
• Hydrazine,
• Methylsilane,
• Methyl Ethyl Ketone,
• Methyl Vinyl Ketone,
• Propenal,
• Trichloroethylene,
• Tetrahydrofuran,
• Uranyl Fluoride,
• Vinyl Chloride,
• Vinyl Cyanide,
• Vinyl Ether,
• Freon 11,
• Freon 12
